Para aramid filament Introduction
Para-aramid is a kind of aromatic polyamide fiber (aramid fibers), China also known as aramid 1414. The main raw materials for para-aramid are terephthaloyl chloride (TPC) and p-phenylenediamine (PPD).
Para aramid filament
PRODUCTS Features:
1, high specific strength, high modulus, high temperature and flame retardant and other excellent performance
2, the relative density is small, fatigue resistance, shear resistance and dimensional stability and good
And other industries.
Para-aramid filament physical properties：
| P-ARAMID | DECITEX | BREAKING STRENGTH(N) | BREAKING TENACITY(g/de) | ELONGATION AT BREAK(%) | TENSILE MODULUS(gf/den) | HOT AIR SHRINKAGE (@180CX 30MIN) |
| 1000D | 1113 | 226 | 23 | 3.5 | 600 | 1.44 |
| 1500D | 1667 | 338 | 23 | 3.5 | 600 | 1.44 |
| 3000D | 3330 | 686 | 23 | 3.5 | 600 | 1.44 |
Para-aramid staple fiber physical properties：
| Type | Linear Density | Fiber Length | Crimp Frequency EN/INCH | Finish Content (%) | Moisture Regain （%） |
| TS130 | 1.5D | 38 | 6 | 0.45 | 7 |
| TS150 | 1.5D | 51 | 6 | 0.45 | 7 |
Aramid 1414 applications
Composite aramid fiber and resin, rubber and other materials, can greatly reduce the weight of the component, increase the effective load, suitable for the production of aerospace equipment, high-speed trains and yacht shell and so on.
.jpg)
